BT-GV FC/FL series Slab Gate Valve
CAMERON FC/FL Style Slab Gate Valve with Non-rising stem and rising stem design in Manual and Hydraulic

BETTER BT-GV FC/FL series Slab Gate Valve is equivalent to CAMARON model FC & FL series, whose feature is a non-rising stem with a slab gate, full-bore thru-conduit design, floating slab gate and seats, floating seat ring body bushing design to provide safe dependable service. This series of gate valves are made by integral die forging, the body and flanges are integral (non-welding). Shot Blasting for every parts of valve. Phosphate to improve corrosion resistance.

Specifications

• Manufactured and tested in accordance with API Spec 6A
• Forged Steel Body and Bonnet

• A True Bi-Directional Valve

• Low Operating Torque

• API Spec 6A PSL, 1, 2, 3

• Material Classes DD, EE, FF, to NACE MR-01-75

• Connections: Threaded, Butt-weld, Flanged, Union

• Medium available: Oil, Gas, and Water

• Specification Level: PSL1 ~ PSL4

• Performance Requirement: PR1 ~ PR2

• Size from 1 13/16”- 7 1/16”

• Working pressures: 5000-20000 PSI


Application
Well Control System, Drilling Manifolds, X-mas trees

Slab Gate Valve divided into Non-rising stem and rising stem type, also divided into manual and hydraulic type.
