Product name : Flexible Rubber Expansion Joint
Model No. : 32-1600mm
Quality Standard : #API & ISO
Origin : CN
Package : Plywood case / Steel Pallet
HS code : 8431431000
←[Previous Product]
Online Inquiry         Email Us

  Details:

A kind of rubber coupling with good elasticity, high air tightness, good shock absorption and noise reduction effect to be used for pipeline with high pressure and large compensation displacement, easy installation;
Adopt new technology of gas blowing mold, consisting of fabric rubber sphere and loose flange;
No gaskets required, integral rubber flanged design, Flange adopted according to DIN PN16/10, ANSI 150/250/300 lbs., BS, JIS 10K.
Size from 1.25-64 inch (32-1600mm)

No.
Part
Material
1
Body
NR,CR,IIR,NBR,FKM,EPDM
2
Inner & Outer Rubber
NR,CR,IIR,NBR,FKM,EPDM,PTFE
3
Body Support
Nylon cord fabric
4
Reinforcing Ring
Multi-strand coppering steel wire
5
Flange
CS Q235, 304SS, 316SS, Plastic
Working Pressure
1.0 - 2.5Mpa
Burst Pressure
2.0 - 4.5Mpa
Vacuum
400-750Kpa
Working Temperature

-30~+250

Application

Air, Water, Sea Water, Oil, Acid, Alkali, etc.


















If you are interested in above, please feel free to contact our sales for more details.
