Products > Oilfield Sand/Slurry/Mud Pumps > Centrifugal Sand Pump > Type JQB Supreme Shear Pump for mud system
Type JQB Supreme Shear Pump for mud system Type JQB Supreme Shear Pump for mud system Type JQB Supreme Shear Pump for mud system Type JQB Supreme Shear Pump for mud system
Product name : Type JQB Supreme Shear Pump for mud system
Model No. : JQB
Quality Standard : API & ISO
Origin : CN
Package : Plywood case / Steel Pallet
HS code : 8413709990
←[Previous Product]              [Next Product]→
Online Inquiry         Email Us

  Details:

BETTER Shear Pump for Solid Control System

This shear pump creates a high-wear resistant surface and imparts a mechanical action of shearing polymers into the fluid stream. By controlling the impeller size and speed, it can incorporate both liquid and mechanical shear techniques to reduce the size of solids.



Feature

·         Economical and compact method of shearing polymers;

·         Thick, strong, concentric casing with shear impeller;

Technical Parameter

Model

JQB80

JQB100

JQB120

Discharge capacity

80 m3/h

100 m3/h

120m3/h

Pump Head

36 m

40 m

45m

Shearing efficiency

95%

95%

95%

Motor power

37 kW

45 kW

55 kW

Rotate speed of impeller

2200rpm

2200rpm

2200rpm

Inlet diameter

6″

6″

6″

Outlet diameter

5″

5″

5″

Weight

700kg

760kg

1155kg

Overall dimensions

1030×995×1440mm

1030×995×1440mm

1065×995×1470mm
